RGB+ Diamond Light
Rainmin
The RGB+ Diamond LED Light brings a brilliant new dimension to outdoor string lighting with its eye-catching diamond-shaped design that delivers true 360° illumination. Each crystal-clear module spreads vibrant R-G-B-W light evenly in every direction, creating sparkling effects without shadows or hotspots. This 24V DC unit is built tough for demanding installations worldwide, combining low power consumption, rugged IP66 protection, and easy integration into long runs up to 30 meters.
Unique Diamond Shape Design: Striking crystal-like appearance with full 360° beam angle for omnidirectional light spread and stunning visual impact.
Vibrant RGBW Color Mixing: Dual SMD 5054 LEDs with R-G-B-W channels and 16-bit (65,536 levels) grey scale deliver smooth, rich colors and precise dimming.
IP66 Waterproof Rating: Fully protected for year-round outdoor use in rain, snow, or dust.
Low Power & Efficient: Only 0.4W per unit, energy-saving for large-scale projects.
Extended Runs: Supports up to 30 meters before power injection via Power T connector.
Flexible Control: Compatible with SPI/TTL protocols and popular controllers (NEC, NDB, WEC, WEC BOSS, and more).
| Parameter | Value |
|---|---|
| LED Type | SMD 5054 |
| LED Channels | R-G-B-W |
| Grey Scale | 16-bit, 65,536 levels |
| LED Quantity per Unit | 2 |
| Beam Angle | 360° |
| Crust Material | Polycarbonate |
| Waterproof Level | IP66 |
| Working Temperature | -25°C to +60°C |
| Input Voltage | 24V DC |
| Current | 0.017 Amps |
| Power Consumption | 0.4W |
| Wire Type | 20 AWG, UV protected |
| Chip/Meter | Customized |
| Max Distance Before Power Injection | 30 Meters |
| Power Injection | Inline via Power T & 12V power supply |
| Supported Controllers | NEC & NDB / WEC / WEC BOSS / Other SPI/TTL controls |
| Protocol | SPI / TTL |
From architectural facades and building perimeters to holiday light shows, retail displays, landscape features, and event backdrops – the diamond design creates dazzling all-around sparkle. Installers in the US and Europe report faster setup and more professional results thanks to the 360° illumination. Perfect for hotels, shopping malls, theme parks, and private residences seeking eye-catching, long-lasting outdoor lighting.
As a direct factory manufacturer with over 15 years of experience in LED outdoor lighting, we offer strict quality control at every stage – from raw materials to final testing. All products meet international export standards including CE and ROHS. Enjoy fast 7-15 day delivery, full OEM/ODM customization (color, length, connectors), and competitive bulk pricing. Our dedicated support team ensures smooth projects from quote to installation.
Get a quote today for bulk orders or custom string configurations. Contact us now for samples, technical drawings, or personalized lighting solutions – we reply within 24 hours!
