Waterproof Rating: IP66 (Full outdoor protection)
Input Voltage: 12V DC (Low-voltage safety operation)
LED Technology: COB RGB (Chip-on-Board for uniform lighting)
Grayscale: 16-bit (65,536 smooth color transitions)
Power Output: 10W high-intensity illumination
Housing Material: Aluminum + Glass (Premium heat dissipation)
Beam Angle: 180-degree wide flood coverage
Protection: UV protected wiring (18AWG)
Customization: OEM/ODM available
Applications: Architectural, landscape, accent lighting
COB 10W RGB
RAINMIN
| Input Watts: | |
|---|---|
| Beam Angle: | |
| voltage: | |
| Lamp Body Material: | |
| LED Quantity: | |
| Size: | |
| Waterproof Level: | |
Rainmin's COB 10W RGB Flood Light represents the pinnacle of professional outdoor lighting technology. Featuring advanced Chip-on-Board (COB) LED technology, this floodlight delivers exceptional 10W output with perfectly uniform color distribution and 16-bit precision for smooth gradient transitions. The robust aluminum and glass construction ensures optimal heat dissipation and durability, while the IP66 rating guarantees reliable performance in any weather condition. Compatible with major control systems including NEC and WEC, this floodlight is ideal for architectural highlighting, landscape illumination, and commercial applications. Backed by Rainmin's 16 years of manufacturing expertise, we offer complete customization options to meet your specific project requirements.
COB Technology: Chip-on-Board design for uniform, high-intensity illumination
16-bit Color Precision: 65,536 grayscale levels for professional smooth fading
Premium Construction: Aluminum housing with glass cover for optimal heat dissipation
IP66 Protection: Complete weather resistance for harsh outdoor environments
Wide Flood Coverage: 180-degree beam angle for broad area illumination
High Efficiency: 10W power output with excellent lumen maintenance
Professional Control: Compatible with major SPI/TTL control systems
Safe Operation: 12V low-voltage design for public space applications
Physical Parameters:
| Parameter | Specification |
|---|---|
| Model Number | COB 10W RGB Flood Light |
| LED Type | COB RGB |
| LED Quantity | 1 COB module |
| Grayscale | 16-bit (65,536 levels) |
| Beam Angle | 180-degree |
| Housing Material | Aluminum + Glass |
| Waterproof Rating | IP66 |
| Operating Temperature | -25°C to +60°C |
Electrical Parameters:
| Parameter | Specification |
|---|---|
| Input Voltage | 12V DC |
| Current Consumption | 0.83A |
| Power Consumption | 10W |
| Wire Type | 18AWG UV protected |
| Protocol Support | SPI/TTL |
| Supported Controllers | NEC, NDB, WEC, WEC BOSS |
Architectural Lighting: Building facades and structural highlighting
Landscape Illumination: Garden features, trees, and outdoor spaces
Commercial Lighting: Storefronts and signage illumination
Event Production: Stage and outdoor event lighting
Public Space Lighting: Parks, monuments, and municipal areas
Security Lighting: Perimeter and area security illumination
Creative Installations: Art and decorative lighting projects
Rainmin Lighting: Expert in Professional Outdoor Lighting Solutions
With 16+ years of specialized manufacturing experience, Rainmin provides:
Custom housing designs and color options
Specialized optical engineering for specific beam patterns
Custom firmware for unique lighting sequences
International safety certification support
Technical guidance for large-scale installations
Competitive OEM pricing for volume orders
Q: What is the advantage of COB technology?
A: COB provides more uniform lighting without multiple shadows, higher lumen density, and better heat management
Q: Can this light be used in extreme weather conditions?
A: Yes, the IP66 rating ensures protection against heavy rain, dust, and extreme temperatures
Q: What controllers are compatible?
A: Compatible with NEC, WEC, and other SPI/TTL based control systems
Q: Can you customize the beam angle?
A: Yes, we can provide different optical configurations for specific beam patterns
Q: Is professional installation required?
A: While designed for professional use, the low-voltage design allows for safer installation
With over 16 years of specialized expertise in outdoor and architectural lighting, Rainmin has established itself as a leading manufacturer for lighting designers, architects, and OEM clients worldwide. We combine advanced LED technology with robust engineering to create lighting solutions that withstand environmental challenges while delivering exceptional visual performance.
Our Custom Capabilities:
• Complete product customization: housing designs, optical systems, mounting solutions
• Specialized thermal management engineering
• Custom firmware for unique lighting effects and control
• International certification support (CE, ROHS, UL)
• Large-scale production capacity with quality assurance
Technical Expertise:
COB LED technology and optical design
Weather-resistant material engineering
Thermal management systems
Professional control system integration
Installation and technical support
Partner Benefits:
• Custom product development from concept to production
• Competitive OEM pricing for volume projects
• Technical documentation and certification support
• Global logistics and supply chain management
• Dedicated technical support team
Rainmin - Professional Lighting Solutions for Demanding Applications
