200W Flood Light
RAINMIN
| voltage: | |
|---|---|
| LED Quantity: | |
| LED Type: | |
| Beam Angle: | |
| Crust Material: | |
| Working Temperature: | |
| Grey Scale: | |
| Category | Specifications |
|---|---|
| Physical Parameters | |
| LED Type | SMD3535 |
| LED Channels | R-G-B |
| Gray Scale | 12-bit, 4,096 levels |
| LED Quantity | 48 LEDs |
| Beam Angle | 3.5°, 25°, 45° (Optional) |
| Material | Aluminum + Glass |
| Waterproof Level | IP66, Outdoor use |
| Working Temperature | -25°C to +60°C |
| Electrical Parameters | |
| Input Voltage | AC 100V-240V |
| Power | 200W |
| Control System | |
| Supported Controllers | NEC & NDB, WEC, WEC BOSS/Other controls |
| Protocol | SPI/TTL |
Product Features
High-Output 200W Performance: Powerful illumination for large-area and long-distance applications
Selectable Beam Angles: Choose from 3.5° (spot), 25° (medium), or 45° (flood) for versatile lighting effects
Professional RGB Color System: 12-bit control with 4,096 color shades for smooth transitions
Industrial-Grade Construction: Aluminum housing with tempered glass for optimal heat dissipation
Universal Voltage Compatibility: AC 100V-240V input for worldwide use
IP66 Weatherproof Rating: Complete protection against dust and heavy rain for outdoor durability
Advanced SMD3535 LEDs: High-efficiency chips delivering bright, consistent output
Application Scenarios
Stage and concert lighting for professional events
Architectural facade lighting for tall buildings
Sports stadium and arena illumination
Industrial area and warehouse lighting
Monument and landmark highlighting
Large outdoor event and festival lighting
Security lighting for large perimeter areas
Company Strengths
15+ years of experience in professional high-power LED manufacturing
Strict quality control with CE, RoHS, and IP66 certifications
Advanced thermal management technology for long lifespan
Customizable solutions for OEM/ODM projects
Global technical support and after-sales service
Competitive pricing with reliable delivery schedules
FAQ
Q: What is the maximum projection distance of the 3.5° beam angle version?
A: The 3.5° narrow beam can project effectively over 150+ meters, making it ideal for long-distance applications.
Q: Can this floodlight operate in extreme weather conditions?
A: Yes, with IP66 rating and -25°C to +60°C operating range, it performs reliably in harsh environments.
Q: Is the power supply included with the fixture?
A: The fixture operates on AC 100V-240V directly, no external power supply is needed.
Q: How many units can be connected to a single controller?
A: Depending on the controller capacity, typically 8-16 units can be connected in series with proper power management.
Q: Can I customize the beam angle for specific projects?
A: Yes, we offer custom beam angles for OEM projects with sufficient order quantity.
